Stuart Turner Pulse Trade 25/60-130 Domestic Circulating Pump

Residential Circulator - Cast Iron Single Union

The NEW STUART PULSE Trade 25/60-130 premium circulator is capable of flow rates up to 3.6 m³/hour and heads up to 6 metres.

Suitable as an ideal replacement for existing 130mm fitting length stand-alone heating system circulators whilst offering superior energy efficiency, reliability and ease of use.

The STUART PULSE TRADE 25/60-130 circulator also features automatic adapt, proportional pressure, constant pressure and constant speed operating modes and is supplied with a 1.3m power cable, shrouded connector and 5 year warranty as standard (Subject to Manufacturers T&C's).

• Automatic adapt, proportional pressure, constant pressure and constant speed operating modes
• Automatic night setback
• Power range setting adjustable to 4m or 6m
• EEI ≤ 0.20 (ErP compliant - best in class)
• LED display control panel
• Anti-lock function
• Insulation shell included
• Shrouded connector included
• 1.3m cable included
• ECM permanent magnet technology
• Built-in over-current, temperature and overvoltage protection
• G 1½ threaded connection


Applications

• Hot water heating systems
• Underfloor heating, pre-plumbed cylinder and boiler applications
• Air conditioning and ventilation systems
